Metal resistant label 60x25

Released Date: Jan 01,2022 Article Source: Suzhou Zhiguan Yisheng Information Technology Co., LTD
Metal-resistant tag60x25Applicable surface Suitable for all surfaces, optimized design is especially suitable for metal surfaces Suitable for installation of tubular, curved and curved surfaces The labels are applicable to pipe, curved, and curved surfaces. For more installation information, see Installation guide

  Suzhou Zhiguan Yisheng Information Technology Co., Ltd. has been committed to the Internet of Things since its inceptionRFIDResearch and implementation of industry application technology. For years of service1000+Home to all types of customers.

  Electronic parameter

  Metal-resistant tag60x25

6025Product drawing

  Device type Class 1Generation 2 Passive UHFRFID transponder

  Communication protocol EPCGlobal Class1 Gen2ISO 18000-6C

  Operating frequency Global 865-928 MHz

  IC Impinj Monza R6M

  Memory allocation  EPC 96 bit; TID 96 bit with 48 bit serial number
  EPC Memory content Tags are written uniquely by default

  Read-write distance(2W ERP)

  Metal surface read-write distance can reach4.5meter/15feet

  The reading and writing distance of plastic surface can reach1.5meter15feet

  Liquid turnover tank surface reading and writing distance can reach3meter/10feet

  Metal-resistant tag60x25

  Applicable surface Suitable for all surfaces, optimized design is especially suitable for metal surfaces

  Suitable for installation of tubular, curved and curved surfaces

  The labels are applicable to pipe, curved, and curved surfaces. For more installation information, see Installation guide

  Read and write distance is based on theoretical values in a non-reflective environment, and different mounting surfaces can affect the actual read and write distance.

  Mechanical parameter

  Label surface material

  The label surface material is polypropylene resin with a proprietary white coating, zebra is recommended5095Resin carbon strip

  Adhesive backing material

  Strong adhesive for any surface, including low surface engineering plastics

  weight 0.6g

  Mode of delivery Each roll500Tablet valid label, invalid label usedxXXIdentification, general effective pass rate>95%

  Tag spacing 3048millimeter/1.2inches

  Core inner diameter 76millimeter13inches

  Product size 60x25x12millimeter/2.36x098x0.047inches

  Metal-resistant tag60x25 Environmental tolerance

  Operating temperature -35℃to+85℃/-31Fto+185F

  Maximum heat resistance temperatureendurable+110℃/230FThe high temperature does not exceed10minutes

  External temperature -35℃to+85℃/-31Fto+185F

  Water resistance IP68,Tolerable in1Immersion test in meters of water5Hour (s)

  Cleaning resistance  Can withstand industrial-grade cleaning in standard solvents, but depends on the cleaning process for the end-use environment

  Chemical resistance

  Exposure to the following solvents showed no physical or performance changes:·

  Exposure to sulfuric acid(10%pH2)In the168Hour (s)

  Exposure to motor oil168Hour (s)

  Salt water exposure(concentration10%)In the168Hour (s)

  Exposed to sodium hydroxide(concentration10%pH13)In the30Minutes should avoid contact with acetone

  Storage environmentAt temperature+20℃Relative humidity50%The environment is1years

  Installation mode

  When installing labels, ensure that:

  Select a smooth surface with no lumps under the label

  Avoid touching the backing glue and chip position

  moreRFIDFor products and solutions, please visit our website( )Or online customer service (13771886689) Consultation
